Brand: Tein
Product: S.Tech Type Spring Set – SKHK8-S1B00

SPECIFICATIONS:
Series: S.Tech
Included: Front & Rear, Left & Right Springs
Spring Rate N/mm (kgf/mm):
– Front: 52.3 (5.3)
– Rear: 47.1 (4.8)
Free Length (mm):
– Front: 230
– Rear: 285
Inner Diameter (mm):
– Front: N/A
– Rear: N/A

PRODUCT NOTES:
– Civic Type R FK8 (09/2017~08/2022):
Stock Height Difference (mm):
– Front: -25
– Rear: -25
– Civic Type R FL5 (09/2022~):
Stock Height Difference (mm):
– Front: -20
– Rear: -25

COMPATIBILITY NOTES:
– Civic Type R FK8 09/2017~08/2022: Excessive Body Roll Is Suppressed By Right Amount Of Ride Drop, To Get The Most Out Of The Original Car’s Comfortable Ride.
– Civic Type R FL5 09/2022~: Excessive Body Roll Is Suppressed By Right Amount Of Ride Drop, To Get The Most Out Of The Original Car’s Comfortable Ride.
– Civic Type R FL5 09/2022~: Ft: Cut Bump Rubber At 20mm From The Bottom And Use The Upper Portion. Rr: Cut Bump Rubber At 10mm From The Bottom And Use The Upper Portion.
