Tein Street Advance Z Coilover Suspension Kit – Z32

This series has been developed in succession of the long running Street Advance lineup providing the ultimate full function coilover setup with great cost performance. A great option for those who want to increase their car’s performance potential while maintaining overall ride comfort in addition to more control on ride height. Multiple damper adjustment ability sets this setup apart from the Street Basis Z series and can also be used in conjunction with the EDFC setup. Quality materials, design, construction and finish to keep the kit looking and performing in top condition.

Product: Street Advance Z Coilover Suspension Kit – GSN22-91SS2

SPECIFICATIONS:
Series: Street Advance Z
Damping force adjustment:
– Front: 16-level
– Rear: 16-level
Mounts:
– Front: UPPER MOUNTS not included, please use OEM
– Rear: UPPER MOUNTS not included, please use OEM
Ride Height Adjustment:
– Front: No
– Rear: No
Spring Rate N/mm (kgf/mm):
– Front: 68.6 (7.0)
– Rear: 49.0 (5.0)
Free Length (mm):
– Front: 215
– Rear: 275
Inner Diameter (mm):
– Front: N/A
– Rear: N/A

PRODUCT NOTES:
– Electronic Damping Force Controller Set-up: Controller (EDFC5 PN: EDK04-R6655​ or Active Pro PN: EDK04-Q0349​) + Motor Kit (PN: EDK05-10120​) [Optional GPS Kit PN: EDK07-P8022​]
– Fairlady Z CZ32 (07/1989~08/2000):
Stock Height Difference (mm):
– Front: -20
– Rear: -15
Maximum adjustment range (mm):
– Front: -66 to +0
– Rear: -59 to +9
Recommended adjustment height range (mm):
– Front: -30 to -10
– Rear: -25 to -5
– Fairlady Z GCZ32 (07/1989~08/2000):
Stock Height Difference (mm):
– Front: -20
– Rear: -15
Maximum adjustment range (mm):
– Front: -66 to +0
– Rear: -59 to +9
Recommended adjustment height range (mm):
– Front: -30 to -10
– Rear: -25 to -5
– Fairlady Z GZ32 (07/1989~08/2000):
Stock Height Difference (mm):
– Front: -20
– Rear: -15
Maximum adjustment range (mm):
– Front: -66 to +0
– Rear: -59 to +9
Recommended adjustment height range (mm):
– Front: -30 to -10
– Rear: -25 to -5
– Fairlady Z Z32 (07/1989~08/2000):
Stock Height Difference (mm):
– Front: -20
– Rear: -15
Maximum adjustment range (mm):
– Front: -66 to +0
– Rear: -59 to +9
Recommended adjustment height range (mm):
– Front: -30 to -10
– Rear: -25 to -5

COMPATIBILITY NOTES:
– Fairlady Z CZ32 07/1989~08/2000: The Setting Is Mainly Focused On Improvement Of Ride Comfort For Everyday Driving On City Streets Etc. Body Roll Is Reduced To Further Improve Stability At High Speed.
– Fairlady Z GCZ32 07/1989~08/2000: The Setting Is Mainly Focused On Improvement Of Ride Comfort For Everyday Driving On City Streets Etc. Body Roll Is Reduced To Further Improve Stability At High Speed.
– Fairlady Z GZ32 07/1989~08/2000: The Setting Is Mainly Focused On Improvement Of Ride Comfort For Everyday Driving On City Streets Etc. Body Roll Is Reduced To Further Improve Stability At High Speed.
– Fairlady Z Z32 07/1989~08/2000: The Setting Is Mainly Focused On Improvement Of Ride Comfort For Everyday Driving On City Streets Etc. Body Roll Is Reduced To Further Improve Stability At High Speed.

Nissan Fairlady Z CZ32 VG30DETT (07/1989-07/1993)
Nissan Fairlady Z CZ32 VG30DETT (08/1993-09/1994)
Nissan Fairlady Z CZ32 VG30DETT (10/1994-12/1996)
Nissan Fairlady Z CZ32 VG30DETT (01/1997-07/2000)
Nissan Fairlady Z GCZ32 VG30DETT (07/1989-07/1993)
Nissan Fairlady Z GCZ32 VG30DETT (08/1993-09/1994)
Nissan Fairlady Z GCZ32 VG30DETT (10/1994-12/1996)
Nissan Fairlady Z GCZ32 VG30DETT (01/1997-07/2000)
Nissan Fairlady Z GZ32 VG30DE (07/1989-07/1993)
Nissan Fairlady Z GZ32 VG30DE (08/1993-09/1994)
Nissan Fairlady Z GZ32 VG30DE (10/1994-12/1996)
Nissan Fairlady Z GZ32 VG30DE (01/1997-07/2000)
Nissan Fairlady Z Z32 VG30DE (07/1989-07/1993)
Nissan Fairlady Z Z32 VG30DE (08/1993-09/1994)
Nissan Fairlady Z Z32 VG30DE (10/1994-12/1996)
Nissan Fairlady Z Z32 VG30DE (01/1997-07/2000)
