Tomei Fuel Delivery Pipe Blue Alumite DENSO / DeatschWerks AN6 Fittings – RB26DETT

Brand: Tomei
Product: Fuel Delivery Pipe DENSO / DeatschWerks AN6 Fittings – RB26DETT
Part Num: 186006

SPECIFICATIONS:
Material: Billet Aluminum
Finish: Blue Alumite
Injector Type: DENSO
Injector Fitting Diameter (mm): 10.90
Fittings Type: AN6
Internal Capacity Volume (cc): 160
Weight (Including Fittings) (g): 690
Kit Contents:
– Pipe
– Adapter(3)
– O-Ring(3)
– 8mm Bolt(2)
– Spacer(2)

PRODUCT NOTES:
If return hole in the centre is not used, it can be blocked with a blind plug. An O-ring is used at the plug ensure a secure seal.

COMPATIBILITY NOTES:
DENSO:
-700cc 183008 (Old Type)
DeatschWerks:
-555cc 42M-01-05506R
-800cc 42M-01-08006R
-1000cc 42M-01-10006R
