HKS Coilover Suspension Full Kit Hipermax R

Brand: HKS
Product: Coilover Suspension Full Kit Hipermax R – S2000 AP1 AP2

SPECIFICATIONS:

Series: Hipermax R
Spring Rate N/mm (kgf/mm):
– Front: 157 (16.0)
– Rear: 157 (16.0)
Free Height (mm):
– Front: 170
– Rear: 150
Recommended Range to change Spring Rate N/mm (kgf/mm):
– Front: ±20 ( 2 )
– Rear: ±20 ( 2 )
Damper Force (Rebound/Damping):
– Front: 1515 / 441
– Rear: 1152 / 373
– Note: Damping force is at piston speed 0.1m/sec.
Default position of Dial:
– Front: 15
– Rear: 15
Damping Force Adjustment:
– Front: 30 Steps
– Rear: 30 Steps
Height Adjustable Lower Bracket:
– Front: Yes
– Rear: Yes
Upper Mount:
– Front: Pillow Ball
– Rear: Pillow Ball
Damper Layout:
– Front: Normal
– Rear: Normal
Damper/Spring Layout:
– Front: Coilover
– Rear: Coilover
Damping force adjustable with Wire:
– Front: N/A
– Rear: Yes
Helper Spring (Spring Rate N/mm):
– Front: 19.8
– Rear: 19.8
Ride Height Specification –
-Default Ride Height Change (mm):
— Front: -29
— Rear: -28
-Ride Height Adjustability Range (mm):
— Front: 3 ~ -59
— Rear: 0 ~ -64

PRODUCT NOTES:
2 Year or 40K km Manufacturer Warranty
Installation Manual PDF: https://www.hks-power.co.jp/product_db/hipermax/db/31849
